DJI Mavic 3 Thermal

by DJI

SKU CB.202209230395
Original price $5,498.00 - Original price $6,657.00
Original price
$5,498.00
$5,498.00 - $6,657.00
Current price $5,498.00
13 Reviews
| 5 answered questions
Availability:
In stock
Availability:
In stock
Availability:
In stock
Availability:
In stock
Availability:
In stock
Availability:
In stock

Shield

Key Features

Worry Free Basic:
Up to two paid replacements can be offered within one year after the product is activated. In addition, it also comes with 1 standard maintenance service.

Worry Free Basic 2-Year:
Up to four paid replacements can be offered within two years after the product is activated. In addition, it also comes with 1 standard maintenance service.

Worry Free Plus:
With a coverage limit equivalent to the product's value, an unlimited number of free repairs can be offered within one year after the product is activated and includes 1 standard maintenance service. Also includes Flyaway Coverage!

**All Mavic 3 Enterprise Series Aircraft require activation of the DJI Care Enterprise. Activation of the DJI Care Enterprise is not automatic.**

Remote ID Ready
Compatibility
In the Box

Standard:
Mavic 3T Aircraft x1
Mavic 3 Flight Battery x1
MicroSD Card 64GB x1
Gimbal Protector x1
Mavic 3 Enterprise Series Propellers (Pair) x1
RC Pro Enterprise x1
Screwdriver x1
USB-C Power Adapter (100W) x1
100W Power Adaptor AC Cable  x1
USB-C Cable x1
USB-C to USB-C Cable x1
Protector Case x1

---

Battery Bundle:
Mavic 3T Aircraft x1
Mavic 3 Flight Battery x1
MicroSD Card 64GB x1
Gimbal Protector x1
Mavic 3 Enterprise Series Propellers (Pair) x1
RC Pro Enterprise x1
Screwdriver x1
USB-C Power Adapter (100W) x1
100W Power Adaptor AC Cable  x1
USB-C Cable x1
USB-C to USB-C Cable x1
Protector Case x1
DJI Mavic 3 Enterprise Series Battery Kit x1

DJI Mavic 3 Thermal

"Thanks for checking in Chris.  The M3T is amazing and is really exceeding my expectations on pretty much every front.  We have used it a few times to locate a few people in wooded areas, and the thermal camera is great at being able to pick out a heat signature through the trees.  So far all is going perfectly with the unit, and we are very happy with it.  Thanks!"

Sgt. Steve Webb
St. Clair Police Department



Your Everyday Commercial Drone

The Mavic 3 Enterprise Series redefines industry standards for small commercial drones. With a mechanical shutter, a 56× zoom camera, and an RTK module for centimeter-level precision, the Mavic 3E brings mapping and mission efficiency to new heights. A thermal version is available for firefighting, search and rescue, inspection, and night operations.

COMPACT AND PORTABLE | 4/3 CMOS WIDE CAMERA | 56x HYBRID ZOOM | MECHANICAL SHUTTER | 45-MIN MAX FLIGHT TIME | DJI O3 ENTERPRISE TRANSMISSION | CENTIMETER-LEVEL POSITIONING WITH RTK | HIGH-VOLUME LOUDSPEAKER

Compact and Portable

Streamlined and compact, the DJI Mavic 3 Enterprise Thermal can be carried in one hand and deployed at a moment's notice. Perfect for beginner and veteran pilots alike, the DJI Mavic 3 bundle is built to perform on lengthy missions.

Two Models, Countless Applications

DJI Mavic 3E

Wide: 4/3 CMOS, 20MP, Mechanical Shutter | Tele: Equivalent Focal Length: 162mm, 12MP, 56× Hybrid Zoom

DJI Mavic 3T

Wide: Equivalent Focal Length: 24mm, 48MP | Zoom: Equivalent Focal Length: 162mm, 12MP, 56× Hybrid Zoom | Thermal: DFOV: 61°, Equivalent Focal Length: 40mm, Resolution 640 × 512

Premium Camera Performance

Survey with Speed

DJI Mavic 3 Enterprise Thermal's wide-angle 4/3 CMOS, 20MP sensor has a mechanical shutter to prevent motion blur and supports rapid 0.7-second interval shooting. Complete mapping missions with extraordinary efficiency without the need for Ground Control Points.

Improved Low-Light Performance

Mavic 3E's Wide camera has large 3.3μm pixels that, together with intelligent low-light mode, offer significantly improved performance in dim conditions.

Focus and Find

Both Mavic 3E and Mavic 3T are equipped with a 12MP Zoom Camera, supporting up to 56× Max Hybrid Zoom to see essential details from afar.

See the Unseen

The DJI Mavic 3 bundle's thermal camera has 640 × 512 resolution and supports point and area temperature measurement, high temperature alerts, color palettes, and isotherms to help you find your targets and make quick decisions.

Simultaneous Split-Screen Zoom

The DJI Mavic 3 bundle's thermal and zoom cameras support 28× continuous side-by-side zoom for easy comparisons.

Exceptional Operational Efficiency

Batteries Optimized For Endurance

45-min flight durations let you cover more ground each mission, for surveying of up to 2 square kilometers in a single flight. Max Flight Time: 45 Minutes. Surverying Area in a Single Flight: 2 Square Kilometers.

Fast charge batteries with 100W charging hub, or directly charge the drone with 88W fast charging. Charging Hub: 100W, Aircraft 88W.

Next-Generation Image Transmission

Quad-antenna O3 Enterprise Transmission enables more stable connections in a wide variety of complex environments.

Omnidirectional Sensing for Safe Flying

Equipped with wide-angle lenses on all sides for omnidirectional obstacle avoidance with zero blind spots. Adjust proximity alarms and braking distance depending on mission requirements. Advanced RTH automatically plans the optimal route home, saving power, time, and hassle. APAS 5.0 enables automatic rerouting around obstacles, so you can fly with peace of mind.

Full Software Suite

DJI Pilot 2

A revamped Enterprise flight interface designed to improve piloting efficiency and flight safety. Drone and payload controls can be easily accessed with one tap. Clear presentation of flight details and navigational information improves user experience together with support for various route types.

DJI FlightHub 2

All-in-one cloud drone operations management for your fleet with support for live annotations and cloud mapping for seamless ground-to-cloud synergy. Efficiently manage inspection operations with route planning and mission management.

DJI Terra

Full featured mapping software for all stages of work, from mission planning to processing of 2D and 3D models.

DJI Thermal Analysis Tool 3.0

Analyze, annotate, and process images captured by M3T using DTAT 3.0 to detect temperature abnormalities in your inspections.

User Data Security

Local Data Mode | One-Tap Clear All Device Data | AES-256 Video Transmission Encryption | Cloud API

Aircraft

Weight (with propellers, without accessories) [1]

DJI Mavic 3T: 920 g



Max Takeoff Weight

DJI Mavic 3T: 1,050 g



Dimensions

Folded (without propellers): 221×96.3×90.3 mm (L×W×H)
Unfolded (without propellers): 347.5×283×107.7 mm (L×W×H)



Diagonal Distance

380.1 mm



Max Ascent Speed

6 m/s (Normal Mode)
8 m/s (Sport Mode)



Max Descent Speed

6 m/s (Normal Mode)
6 m/s (Sport Mode)



Max Flight Speed (at sea level, no wind)

15 m/s (Normal Mode)
Forward: 21 m/s, Side: 20 m/s, Backward: 19 m/s (Sport Mode) [2]



Max Wind Speed Resistance

12 m/s [3]



Max Take-off Altitude Above Sea Level

6000 m (without payload)



Max Flight Time (no wind)

45 mins [4]



Max Hover Time (no wind)

38 mins



Max Flight Distance

32 km



Max Pitch Angle

30° (Normal Mode)
35° (Sport Mode)



Max Angular Velocity

200°/s



GNSS

GPS+Galileo+BeiDou+GLONASS (GLONASS is supported only when the RTK module is enabled)



Hovering Accuracy

Vertical: ±0.1 m (with Vision System); ±0.5 m (with GNSS); ±0.1 m (with RTK)
Horizontal: ±0.3 m (with Vision System); ±0.5 m (with High-Precision Positioning System); ±0.1 m (with RTK)



Operating Temperature Range

-10° to 40° C (14° to 104° F)



Internal Storage

N/A



Motor Model

2008



Propeller Model

9453F Propellers for Enterprise



Beacon

Built into the aircraft



Wide Camera

Sensor

DJI Mavic 3T: 1/2-inch CMOS, Effective pixels: 48 MP



Lens

DJI Mavic 3T:
FOV: 84°
Format Equivalent: 24 mm
Aperture: f/2.8
Focus: 1 m to ∞



ISO Range

DJI Mavic 3T: 100-25600



Shutter Speed

DJI Mavic 3T:
Electronic Shutter: 8-1/8000 s



Max Image Size

DJI Mavic 3T: 8000×6000



Still Photography Modes

DJI Mavic 3T:
Single: 12 MP/48 MP
Timed: 12 MP/48 MP
JPEG: 2/3/5/7/10/15/20/30/60 s*
Panorama: 12 MP (raw image); 100 MP (stitched image)

* Shooting 48MP photo does not support 2s interval
Smart Low-light Shooting: 12 MP



Video Resolution

H.264
4K: 3840×2160@30fps
FHD: 1920×1080@30fps



Bitrate

DJI Mavic 3T:
4K: 85 Mbps
FHD: 30 Mbps



Supported File Formats

exFAT



Photo Format

DJI Mavic 3T: JPEG



Video Format

MP4 (MPEG-4 AVC/H.264)



Tele Camera

Sensor

1/2-inch CMOS, Effective pixels: 12 MP



Lens

FOV: 15°
Format Equivalent: 162 mm
Aperture: f/4.4
Focus: 3 m to ∞



ISO Range

DJI Mavic 3T: 100-25600



Shutter Speed

Electronic Shutter: 8-1/8000 s



Max Image Size

4000×3000



Photo Format

JPEG



Video Format

MP4 (MPEG-4 AVC/H.264)



Still Photography Modes

DJI Mavic 3T:
Single: 12 MP
Timed: 12 MP
JPEG: 2/3/5/7/10/15/20/30/60 s
Smart Low-light Shooting: 12 MP


Video Resolution

H.264
4K: 3840×2160@30fps
FHD: 1920×1080@30fps



Bitrate

DJI Mavic 3T:
4K: 85 Mbps
FHD: 30 Mbps



Digital Zoom

8x (56x hybrid zoom)



Thermal Camera [5]

Thermal Imager

Uncooled VOx Microbolometer



Pixel Pitch

12 μm



Frame Rate

30 Hz



Lens

DFOV: 61°
Format Equivalent: 40 mm
Aperture: f/1.0
Focus: 5 m to ∞



Sensitivity

≤50 mK@F1.0



Temperature Measurement Method

Spot Meter, Area Measurement



Temperature Measurement Range

-20° to 150° C (-4° to 302° F, High Gain Mode)
0° to 500° C (32° to 932° F, Low Gain Mode)



Palette

White Hot/Black Hot/Tint/Iron Red/Hot Iron/Arctic/Medical/Fulgurite/Rainbow 1/Rainbow 2



Photo Format

JPEG (8-bit)
R-JPEG (16-bit)



Video Resolution

640×512@30fps



Bitrate

6 Mbps



Video Format

MP4 (MPEG-4 AVC/H.264)



Still Photography Modes

DJI Mavic 3T:
Single: 640×512
Timed: 640×512
JPEG: 2/3/5/7/10/15/20/30/60 s



Digital Zoom

28x



Infrared Wavelength

8-14 μm



Infrared Temperature Measurement Accuracy

±2° C or ±2% (using the larger value)



Gimbal

Stabilization

3-axis (tilt, roll, pan)



Mechanical Range

DJI Mavic 3T:
Tilt: -135° to 45°
Roll: -45° to 45°
Pan: -27° to 27°



Controllable Range

Tilt: -90° to 35°
Pan: Not controllable



Max Control Speed (tilt)

100°/s



Angular Vibration Range

±0.007°



Sensing

Type

Omnidirectional binocular vision system, supplemented with an infrared sensor at the bottom of the aircraft.



Forward

Measurement Range: 0.5-20 m
Detection Range: 0.5-200 m
Effective Sensing Speed: Flight Speed ≤15 m/s
FOV: Horizontal 90°, Vertical 103°



Backward

Measurement Range: 0.5-16 m
Effective Sensing Speed: Flight Speed ≤12 m/s
FOV: Horizontal 90°, Vertical 103°



Lateral

Measurement Range: 0.5-25 m
Effective Sensing Speed: Flight Speed ≤15 m/s
FOV: Horizontal 90°, Vertical 85°



Upward

Measurement Range: 0.2-10 m
Effective Sensing Speed: Flight Speed ≤6 m/s
FOV: Front and Back 100°, Left and Right 90°



Downward

Measurement Range: 0.3-18 m
Effective Sensing Speed: Flight Speed ≤6 m/s
FOV: Front and Back 130°, Left and Right 160°



Operating Environment

Forward, Backward, Lateral, and Upward: Surface with a clear pattern and adequate lighting (lux >15)
Downward: Diffuse reflective surface with diffuse reflectivity>20% (e.g. walls, trees, people) and adequate lighting (lux >15)



Video Transmission

Video Transmission System

DJI O3 Enterprise Transmission



Live View Quality

Remote Controller: 1080p/30fps



Operating Frequency [6]

2.400-2.4835 GHz
5.725-5.850 GHz



Max Transmission Distance (unobstructed, free of interference) [7]

DJI Mavic 3T:
FCC: 15 km
CE: 8 km
SRRC: 8 km
MIC: 8 km



Max Transmission Distance (Obstructed) [8]

Strong Interference (dense buildings, residential areas, etc.): 1.5-3 km (FCC/CE/SRRC/MIC)
Medium Interference (suburban areas, city parks, etc.): 3-9 km (FCC), 3-6 km (CE/SRRC/MIC)
Low Interference (open spaces, remote areas, etc.): 9-15 km (FCC), 6-8 km (CE/SRRC/MIC)


Max Download Speed[9]

15 MB/s (with DJI RC Pro Enterprise)



Latency (depending on environmental conditions and mobile device)

Approx. 200 ms



Antenna

4 Antennas, 2T4R



Transmission Power (EIRP)

2.4 GHz: <33 dBm (FCC), <20 dBm (CE/SRRC/MIC)
5.8 GHz: <33 dBm (FCC), <30 dBm (SRRC), <14 dBm (CE)



DJI RC Pro Enterprise

Video Transmission System

DJI O3 Enterprise Transmission



Max Transmission Distance (unobstructed, free of interference) [7]

FCC: 15 km
CE/SRRC/MIC: 8 km



Video Transmission Operating Frequency [6]

2.400-2.4835 GHz
5.725-5.850 GHz



Antenna

4 Antennas, 2T4R



Video Transmission Transmitter Power (EIRP)

2.4 GHz: <33 dBm (FCC), <20 dBm (CE/SRRC/MIC)
5.8 GHz: <33 dBm (FCC), <14 dBm (CE), <23 dBm (SRRC)



Wi-Fi Protocol

802.11 a/b/g/n/ac/ax
Support 2×2 MIMO Wi-Fi



Wi-Fi Operating Frequency [6]

2.400-2.4835 GHz
5.150-5.250 GHz
5.725-5.850 GHz



Wi-Fi Transmitter Power (EIRP)

2.4 GHz: <26 dBm (FCC), <20 dBm (CE/SRRC/MIC)
5.1 GHz: <26 dBm (FCC), <23 dBm (CE/SRRC/MIC)
5.8 GHz: <26 dBm (FCC/SRRC), <14 dBm (CE)



Bluetooth Protocol

Bluetooth 5.1



Bluetooth Operating Frequency

2.400-2.4835 GHz



Bluetooth Transmitter Power (EIRP)

< 10 dBm



Screen Resolution

1920×1080



Screen Size

5.5 inches



Screen

60 fps



Brightness

1,000 nits



Touchscreen Control

10-point multi-touch



Battery

Li-ion (5000 mAh @ 7.2 V)



Charging Type

Recommended to be charged with the included DJI USB-C Power Adapter (100W) or USB charger at 12 V or 15 V



Rated Power

12 W



Storage Capacity

Internal Storage (ROM): 64 GB
Supports a microSD card for expanded capacity.



Charging Time

Approx. 1 hour 30 minutes (with the included DJI USB-C Power Adapter (100W) only charging the remote controller or a USB charger at 15 V)
Approx. 2 hours (with a USB charger at 12 V)
Approx. 2 hours 50 minutes (with the included DJI USB-C Power Adapter (100W) charging the aircraft and remote controller simultaneously)



Operating Time

Approx. 3 hours



Video Output Port

Mini-HDMI port



Operating Temperature Range

-10° to 40° C (14° to 104° F)



Storage Temperature

-30° to 60° C (-22° to 140° F) (within one month)
-30° to 45° C (-22° to 113° F) (one to three months)
-30° to 35° C (-22° to 95° F) (three to six months)
-30° to 25° C (-22° to 77° F) (more than six months)



Charging Temperature

5° to 40° C (41° to 104° F)



Supported DJI Aircraft[10]

DJI Mavic 3E
DJI Mavic 3T



GNSS

GPS+Galileo+GLONASS



Dimensions

Antennas folded and controller sticks unmounted:
183.27×137.41×47.6 mm (L×W×H)
Antennas unfolded and controller sticks mounted:
183.27×203.35×59.84 mm (L×W×H)



Weight

Approx. 680 g



Model

RM510B



Storage

Supported Memory Cards

Aircraft:
U3/Class10/V30 or above is required. A list of recommended microSD cards can be found below.



Recommended microSD Cards

Remote Controller:
SanDisk Extreme PRO 64GB V30 A2 microSDXC
SanDisk High Endurance 64GB V30 microSDXC
SanDisk Extreme 128GB V30 A2 microSDXC
SanDisk Extreme 256GB V30 A2 microSDXC
SanDisk Extreme 512GB V30 A2 microSDXC
Lexar 667x 64GB V30 A2 microSDXC
Lexar High-Endurance 64GB V30 microSDXC
Lexar High-Endurance 128GB V30 microSDXC
Lexar 667x 256GB V30 A2 microSDXC
Lexar 512GB V30 A2 microSDXC
Samsung EVO Plus 64GB V30 microSDXC
Samsung EVO Plus 128GB V30 microSDXC
Samsung EVO Plus 256GB V30 microSDXC
Samsung EVO Plus 512GB V30 microSDXC
Kingston Canvas Go! Plus 128GB V30 A2 microSDXC
Kingston Canvas React Plus 128GB V90 A1 microSDXC

Aircraft:
SanDisk Extreme 32GB V30 A1 microSDHC
SanDisk Extreme PRO 32GB V30 A1 microSDHC
SanDisk Extreme 512GB V30 A2 microSDXC
Lexar 1066x 64GB V30 A2 microSDXC
Kingston Canvas Go! Plus 64GB V30 A2 microSDXC
Kingston Canvas React Plus 64GB V90 A1 microSDXC
Kingston Canvas Go! Plus 128GB V30 A2 microSDXC
Kingston Canvas React Plus 128GB V90 A1 microSDXC
Kingston Canvas React Plus 256GB V90 A2 microSDXC
Samsung PRO Plus 256GB V30 A2 microSDXC


Battery

Capacity

5000 mAh



Standard Voltage

15.4 V



Max Charging Voltage

17.6 V



Type

LiPo 4S



Chemical System

LiCoO2



Energy

77 Wh



Weight

335.5 g



Charging Temperature

5° to 40° C (41° to 104° F)



Charger

Input

100-240 V (AC Power), 50-60 Hz, 2.5 A



Output Power

100 W



Output

Max. 100 W (total)
When both ports are used, the maximum output power of each interface is 82 W, and the charger will dynamically allocate the output power of the two ports according to the load power.



Charging Hub*

Input

USB-C: 5-20 V, 5.0 A



Output

Battery Port: 12-17.6 V, 8.0 A



Rated Power

100 W



Charging Type

Three batteries charged in sequence



Charging Temperature Range

5° to 40° C (41° to 104° F)



RTK Module*

Dimensions

50.2×40.2×66.2 mm (L×W×H)



Weight

24±2 g



Interface

USB-C



Power

Approx. 1.2 W



RTK Positioning Accuracy

RTK Fix:
Horizontal: 1 cm + 1 ppm; Vertical: 1.5 cm + 1 ppm



Speaker*

Dimensions

114.1×82.0×54.7 mm (L×W×H)



Weight

85±2 g



Interface

USB-C



Rated Power

3 W



Max Volume [11]

110 dB @ 1 m



Effective Broadcast Distance [11]

100 m @ 70 dB



Bit Rate

16 Kbps/32 Kbps



Operating Temperature Range

-10° to 40° C (14° to 104° F)



Other

Notes

[1] The standard weight of the aircraft (including the battery, propellers, and a microSD card). The actual product weight may vary due to differences in batch materials and external factors.
[2] Maximum speed in Sport mode is 19m/s when operating in EU regions.
[3] Max wind speed resistance during takeoff and landing.
[4] Measured with Mavic 3 Enterprise Series flying at a constant speed of 32.4 kph in a windless environment at sea level until the battery reached 0%. Data is for reference only. Please pay attention to RTH reminders in the DJI Pilot 2 app during flight.
[5] DO NOT expose the infrared camera lenses to strong sources of energy such as the sun, lava, or laser beams. Otherwise, the camera sensor may be burned, leading to permanent damage.
[6] In some countries and regions, the 5.8 and 5.1GHz frequencies are prohibited, or the 5.1GHz frequency is only allowed for indoor use. Check local laws and regulations for more information.
[7] Measured in an unobstructed environment free of interference. The above data shows the farthest communication range for one-way, non-return flights (with no payload) under each standard. During your flight, please pay attention to RTH reminders in the DJI Pilot 2 app.
[8] Data tested under different standards in unobstructed environments with typical interference. Uses for reference purposes only and provides no guarantee as to the actual flight distance.
[9] Measured in a laboratory environment with little interference in countries/regions that support both 2.4 GHz and 5.8 GHz. With footage saved on the officially recommended microSD cards. Download speeds may vary depending on actual conditions.
[10] Will support more DJI aircraft in the future. Visit the official website for the latest information.
[11] Data was measured in a controlled environment and is for reference only. Actual use experience may vary depending on software version, sound source, specific environment, and other conditions.

*Optional Accessories. Not Included in the Standard Package

ALL PRODUCTS REQUIRING ACTIVATION ARE NON-RETURNABLE/NON-REFUNDABLE **

* There is a 3% order transaction fee for all processed refunds / canceled orders (except in the case of a DOA product) *

New Returns

Cloud City Drones will take back any new item up to 14 days after receiving your order. Items must be unused and in the original sealed packaging. New items returned 14 days, after the received date, can be returned for a refund minus a 20% restocking fee. No returns are allowed after 30 days. Return shipping costs are to be paid by the purchaser. Any products that are returned damaged and/or defective (except in the case of a DOA return) will be returned to the sender without a refund.

Open Box Returns

Cloud City Drones will take back any new and working item with all the original packaging. There will be a 20% restocking fee. No returns are allowed after 30 days. Return shipping costs are to be paid by the purchaser. Damage from an improper installation is not returnable.  This can include but is not limited to electrical shorting, poorly done soldering, or forceful installation. Any products that are returned damaged and/or defective (except in the case of a DOA return) will be returned to the sender without a refund.

International Returns

International returns are subject to the same terms and conditions as domestic returns. New returns will be accepted for a full refund if the product has not been opened or used. New products returned after 14 days and open box items returned before 30 days are both subject to a 20% restocking fee when refunded. No returns will be accepted after 30 days. Return shipping costs are to be paid by the purchaser. Any products that are returned damaged and/or defective (except in the case of a DOA return) will not be refunded.

DJI DOA Out of Box Returns

DJI’s policy is that if your item is defective out of the box within 10 days of receiving the item, has not been crashed and in original condition, we can exchange the item if the problem can be confirmed by us.

PDF VERSION
