DJI Zenmuse H20T Radiometric Thermal Camera

H For Hybrid.
Multi-sensor payloads that bring a whole new meaning to mission efficiency. The unique intelligence and integrated design provide unprecedented aerial imaging capabilities for a range of commercial drone applications.

All The Sensors You Need in One.
Capture everything. Up close or from a distance. In true living color or thermal. An integrated laser rangefinder (LRF) measures the distance to an object at up to 1200 m away. A powerful, integrated payload that unleashes advanced intelligent capabilities for DJI’s industrial drones.

H20T Quad Sensor Solution

• 20MP Zoom Camera
• 12MP Wide Camera
• 1200m LRF
• 640x512px Radiometric Thermal Camera

H For Hybrid.
Multi-sensor payloads that bring a whole new meaning to mission efficiency. The unique intelligence and integrated design provide unprecedented aerial imaging capabilities for a range of commercial drone applications.

All The Sensors You Need In One.
Capture everything. Up close or from a distance. In true living color or thermal. An integrated laser rangefinder (LRF) measures the distance to an object at up to 1200 m away. A powerful, integrated payload that unleashes advanced intelligent capabilities for DJI’s industrial drone platforms.

H20T Quad Sensor Solution

20MP Zoom Camera
12MP Wide Camera
1200m LRF
640x512px Radiometric Thermal Camera




General Weight
Zenmuse H20: 678±5 g
Zenmuse H20T: 828±5 g

Dimensions
Zenmuse H20: 150×114×151 mm
Zenmuse H20T: 167×135×161 mm

Ingress Protection Rating
IP44

Operating Temperature
-20° to 50° C (Temperature Measurement is only available between -10° to 50° C)

Storage Temperature
-20° to 60° C

Laser Safety
Class 1M (IEC 60825-1:2014)

Supported Aircraft
Matrice 300 RTK

Matrice 350 RTK

Gimbal
Angular Vibration Range
±0.01°

Mount
Detachable

Controllable Range
Pitch: -120° to +30°
Yaw: ±320°

Mechanical Range
Pitch: -132.5° to +42.5°
Yaw: ±330°
Roll: -90° to +60°

Zoom Camera
Sensor
1/1.7" CMOS, 20 MP

Lens
DFOV: 66.6°-4°
Focal length: 6.83-119.94 mm (equivalent: 31.7-556.2 mm)
Aperture: f/2.8-f/11 (normal), f/1.6-f/11 (night scene)
Focus: 1 m to ∞ (wide), 8 m to ∞ (telephoto)

Focus Mode
MF/AF-C/AF-S

Exposure Mode
Auto, Manual

Exposure Compensation
±3.0 (1/3 increments)

Metering Mode
Spot metering, Center-weighted metering

AE LOCK
Supported

Electronic Shutter Speed
1 ~ 1/8000 s

ISO Range
Video: 100 - 25600
Photo: 100 - 25600

Video Resolution
3840x2160@30fps, 1920x1080@30fps

Video Format
MP4

Video Subtitles
Supported

Photo Size
5184 × 3888

Photo Format
JPEG

Wide Camera
Sensor
1/2.3" CMOS, 12 MP

Lens
DFOV: 82.9°
Focal length: 4.5 mm (equivalent: 24 mm)
Aperture: f/2.8
Focus: 1 m to ∞

Exposure Mode
Auto

Exposure Compensation
±3.0 (1/3 increments)

Metering Mode
Spot metering, Center-weighted metering

AE LOCK
Supported

Electronic Shutter Speed
1 ~ 1/8000

ISO Range
Video: 100 - 25600
Photo: 100 - 25600

Video Resolution
1920×1080@30fps

Video Format
MP4

Video Subtitles
Supported

Photo Size
4056 x 3040

Photo Format
JPEG

Laser Rangefinder
Wave Length
905 nm

Measurement Range
3-1200 m (to a vertical surface with ≥12m diameter and 20% reflection rate)

Measurement Accuracy
± (0.2 m + D×0.15%)
D is the distance to a vertical surface

Features
Hybrid Optical Zoom
23×（DFOV：4°，EQV：556.2mm）

Max Zoom
200×（DFOV：0.5°，EQV：4800mm）

One Click Capture
One click to save the video or picture of 3 cameras (zoom, wide and thermal camera) simultaneously

Point to Aim
Double click on the wide/thermal camera view, then the system will automatically move the gimbal to focus on the point of interest

High-Res Grid Photo
Frame an area of interest in wide camera view, and the zoom camera will automatically capture a set of 20 MP images of the area. These images are stored together with an overview image that can be viewed in greater detail.

Night Scene
Supported (zoom camera)

Timestamp
Including GPS, date, and time

Storage
Supported SD Card
MicroSD card (Max capacity: 128 GB, UHS-1 Speed Grade 3 required)

Supported File Systems
FAT32 (≤ 32 GB), exFAT (> 32 GB)

Recommended MicroSD Cards
TOSHIBA EXCERIA PRO 32GB micro SD HC II
SanDisk_Extreme PRO_32GB_3_A1_micro SD V30 HC I
TOSHIBA EXCERIA PRO 64GB micro SD XC II
SanDisk_Extreme PRO_64GB_3_A2_micro SD V30 XC I
SAMSUNG_EVO_128GB_micro SD 3 XC I
TOSHIBA EXCERIA M303E 32GB micro SD HC I
TOSHIBA EXCERIA M303E 64GB micro SD XC I
TOSHIBA EXCERIA M303E 64GB micro SD XC I
TOSHIBA EXCERIA M303 128GB micro SD XC I
SAMSUNG_EVO_64GB_micro SD 3 XC I
